UTC-307GP-ATW0E Phase out All-IN-ONE MACHINE W/DISPLAY, 7"Pcap,N3350,2G RAM,White

All-IN-ONE MACHINE W/DISPLAY, 7"Pcap,N3350,2G RAM,White
  • All-IN-ONE MACHINE W/DISPLAY, 7"Pcap,N3350,2G RAM,White
  • All-IN-ONE MACHINE W/DISPLAY, 7"Pcap,N3350,2G RAM,White
  • All-IN-ONE MACHINE W/DISPLAY, 7"Pcap,N3350,2G RAM,White
  • All-IN-ONE MACHINE W/DISPLAY, 7"Pcap,N3350,2G RAM,White
  • All-IN-ONE MACHINE W/DISPLAY, 7"Pcap,N3350,2G RAM,White
  • All-IN-ONE MACHINE W/DISPLAY, 7"Pcap,N3350,2G RAM,White
  • All-IN-ONE MACHINE W/DISPLAY, 7"Pcap,N3350,2G RAM,White
  • All-IN-ONE MACHINE W/DISPLAY, 7"Pcap,N3350,2G RAM,White
  • All-IN-ONE MACHINE W/DISPLAY, 7"Pcap,N3350,2G RAM,White

  1. Lightweight, fanless system design
  2. Built-in Intel® Celeron® N3350(default)/Pentium® N4200 processor
  3. IP65-rated front panel for water and dust resistance
  4. Pre-perforated removable docking station sections for flexible peripheral installation
  5. Detachable frame design enables stand-alone, panel, or in-wall mount installation
  6. Support PoE technology
  7. Rich I/O and diverse peripheral options
  8. VESA 75 mm standard mounting holes for varied mounting demands
  9. Support Windows 10 IoT, Android 6.0, and Linux Ubuntu 18.04 operating systems
Resources
Resources Download
DatasheetDownloadDriverManualExtended Specifications
Please visit via PC to place order/quote
Contact us for stock info
2 years extended warranty
Make an inquiry
Specifications
Category
Attribute
Value
Processor System
CPU
Intel® Celeron® N3350 1.10GHz
Processor System
OS
Win 10 IoT Enterprise 64bit / Android 6.0 / Android 8.1 / Linux Ubuntu 18.04
Processor System
RAM
2G DDR3L installed
Processor System
Storage
1 x M.2 2242 SSD
Display
Brightness
450 cd/m²
Display
Max. Resolution
WVGA (800 x 480)
Display
Size
7" TFT LCD
Touch Screen
Type
Projected Capacitive
Color
Color
White
I/O Interface
Ethernet
2 x Gigabit Ethernet (1 with PoE)
I/O Interface
Extendable Slot
1 x M.2 key2230, 1 x M.2 key2242
I/O Interface
Serial Port
2 x COM (RS-232)
I/O Interface
Speaker
1 x 2W Speaker
I/O Interface
USB Port
2 x USB3.0, 2 x USB3.0 (optional)
Power
Input Rating
12 V/3 A ~ 24 V/1.5 A (36W ITE Adapter) / Optional IEEE 802.3at/30W PoE
Power
PoE
IEEE 802.3at/30W (Optional)
Enviroment
Operating Humidity
10 ~ 95% @ 40°C non-condensing
Enviroment
Operating Temperature
0~40° C
Enviroment
Shock
10G peak acceleration (11 msec. duration)
Enviroment
Vibration
0.5G
