Memory
Socket
1 x 204-pin SO-DIMM
Memory
Technology
DDR3L 1333 MHz
Processor
CPU
Intel Celeron Processor J1900 Quad Core
Processor
Frequency
2.0 GHz, turbo boost up to 2.42 GHz
Storage
2.5" HDD/SSD
1 x 2.5" SATA Drive bay (Compatible with 12.5mm height)
Storage
SSD
1 x full size mSATA socket, with USB signal co-lay
Environment
Operational Temperature
With extended temperature peripherals: -20 ~ 70° C (-4 ~ 158° F) with 0.7m/s air flow;With 2.5-inch hard disk 0 ~ 45° C (32 ~ 112° F) with 0.7m/s air flow
Environment
Storage Temperature
-40 ~ 85° C (-40 ~ 185° F)
Power
Consumption
Typical 7.3 W, Max. 13.3 W
Power
Input Voltage
9 ~ 36 VDC
Power
Power Adaptor
AC to DC, DC19 V/3.42 A, 65 W (Optional)
Ethernet
LAN1
10/100/1000 Mbps Intel i210 GbE, support Wake On Lan
Ethernet
LAN2
10/100/1000 Mbps Intel I210 GbE, support Wake on LAN
Graphics
Chipset
Intel Celeron J1900 SoC integrated, 7th Gen. Intel Graphic core
Graphics
Dual Display
Yes, VGA + HDMI
Graphics
Graphic Engine
DirectX 11.1, OCL 1.2, OGL 3.2; Encode: H.264, MPEG2/4, VC1, WMV9; Decode: H.264, MPEG2
Audio
Main System
Realtek ALC888S, High Definition Audio. Line-out,Mic-in,Line-in
I/O Interface
Serial Port
2 x RS232,
2 x RS232/ 422/ 485
I/O Interface
USB Interface
1 x USB 3.0, 3 x USB 2.0
Environment
Relative Humidity
95% @ 40° C (non-condensing)
Environment
Shock During Operation
With SSD: 30 G, IEC 60068-2-27, half sine, 11 ms duration
Environment
Vibration During Operation
With SSD: 3 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis.
Certification
EMC
CE/FCC Class A, CCC, BSMI
Certification
Safety Certifications
UL, CCC, BSMI
Expansion
Mini PCI Express
1
Expansion
Mini PCIe #1
1 x Full-size mPCIe with SIM holder
Power Consumption
Max.
13.3W
Power Consumption
Typical
7.3W
Mechanical
Construction
Aluminum housing
Mechanical
Dimensions
264.5 x 68.4 x 133.0 mm (10.41" x 2.69" x 5.24")
Mechanical
Mounting
Din-Rail mounting, Desk/wall-mounting, VESA mounting
Mechanical
Weight
2.3 kg (5.07 lb)
Others
Watchdog timer
255 levels timer interval, setup by software
Software Support
Linux
Support by project
Software Support
Microsoft Windows
WES8, Windows 8, WES7, Windows 7
